Manufactured in the UK to BS EN 13485 Medical Devices: Quality Management Systems. The CPX lockable line valve is designed to have tight shut-off and blow-out-proof stem for protection against pressure surges.
We offer the full range of sizes 15-108mm and have stock readily available for common sizing, so you can keep the project going and on time.
| Additional Info: | The CPX Medical Lockable Line Valve comprises a 2-piece full bore male threaded nickel plated brass ball valve c/w chrome plated brass ball, blow-out proof stem, stem O-ring, Teflon® ball seals, and flat face copper stub pipe assemblies. The copper stub pipe assemblies are manufactured from medical gas copper tube compliant to BS EN 13348 and are factory soldered to brass flat face seal housings chemically cleaned and degreased. The copper pipe stubs are of sufficient length to enable brazing directly to the MPGS utilising fluxless brazing to WKO (82) 1. Flat face housing incorporates Nitrile® or Viton® O-ring seals ensuring 100% gas-tight connections. The chrome-plated valve handle is lockable in the open or closed position by way of a sliding device and a brass padlock is provided to prevent unauthorised or inadvertent operation of the valve. For ease of installation, all brass padlocks are the same size for the full range of ball valves from 15mm to 108mm. All line valves are fully pressure tested for valve tightness and leakage and batch numbered for traceability prior to packing and delivery. They are individually end-capped and sealed in a clear polythene bag to maintain cleanliness. |
|---|---|
| Diameter (mm) | 15, 22, 28, 35, 42, 54, 67, 76, 108 |
| Gas Type | Oxygen, Nitrous Oxide, Entonox, Medical Air-4, Surgical Air-7, Vacuum, Carbon Dioxide, Helium, Hydrogen, Nitrogen, Argon |
