eAdvantage® N2O/O2 Analgesic Gas Mixing and Delivery System

Description
Additional Info
Description

Specifically designed for pain relief during emergencies, childbirth, or painful procedures.

Designed for in-hospital use (ER, Labor and Delivery, Clinics, etc.), the new eAdvantage® provides a variable mixture of nitrous oxide and oxygen, on demand, to a conscious, spontaneously breathing patient for the relief of pain due to childbirth, trauma or other conditions where inhalation analgesia is clinically specified. It only requires the attachment to pressure-regulated medical oxygen and nitrous oxide gas supplies (wall outlet or cylinders), electrical supply or battery, and the attachment of a patient circuit with mouthpiece or facemask and scavenging hose to be ready for use.

Simple controls and abundant safety features make this the ideal device for the accurate delivery of titratable analgesia during labour, trauma, or painful procedures.

The O-Two™ eAdvantage® mixer is groundbreaking. Its ability to deliver the precise amount of gas required for the patient, without any waste or environmental hazards, is unmatched by any other analgesia device on the market. The demand for gas flow is regulated by the spontaneous breath of the patient, thereby preventing any unnecessary gas waste.

Additional Info
Control Circuit Source

Electronic

Pneumatic circuit Gas consumption (L/min)

0.00

Maximum Flow rate

>260 combined or 160 from oxygen input only

Oxygen Concentrations

30-100% continuous adjustment with 5% incremental changes

Trigger sensitivity (cm H2O)

~ -1.0 (non-adjustable)

Inhalation Resistance

0 to -6cm H2O

Exhalation Resistance

0 to 6cm H2O

Input Pressure Range

50-70 PSI

Device Emergency Shut Off

Below 20 PSI O2 input, Below 25% O2 output w/ 3 consecutive breaths or below 21% O2 output immediately, Sensors and/or valve failure

Oxygen Enrichment Flow Rate

40 l/min

Patient connector

15/22mm

Patient Circuit (Single Use)

Dual limb circuit with one-way valves and 19mm scavenging Port Connection on the exhalation limb (O2FLEXICARE)

Device Input Connections

Nitrous Oxide: CGA1040 DISS / Oxygen: CGA1240 DISS

Battery

Li-Ion (01CV9200), Operating time 15-24 hrs

A/C power adapter

100-250V / 4.74A

Display

4.3″ Color TFT

Live Monitoring

Alarms and setting only

Parameter Settings

Control Knob

Lock Key Function

Yes w/ passcode

Dimensions WxDxH

305 x 210 x 130mm

Weight

2.80kg
